Lenovo E30 (Intel) schematic, PS-Note CULV, PS1

The motherboard schematic for Lenovo E30 Intel laptop/notebook, Quanta PS1.
CPU: Penryn SFF
North Bridge: Cantiga SFF GS45/ GS40
South Bridge: ICH9-M SFF
OEM: Quanta Computer Inc.
PROJECT: PS1
Rev: 1A
Format: PDF
Total Pages: 41
File size: 1.21MB
Sale Price: 9.5$

Lenovo E30 Block Diagram:
