Lenovo IdeaPad Y770 schematic, LA-6758P

The motherboard schematic for Lenovo Y770 laptop/notebook, Compal LA-6758P, G470/G570 DIS+UMA+Muxless M/B Schematics Document.
CPU: Intel Sandy Bridge
Discrete VGA AMD Robson XT
Chipset: Intel Cougar Point
OEM: Compal Electronics, Inc.
File Name : G470/G570
Document Number: LA-6758P
Revision: 0.1
Format: PDF
Total Pages: 57
File size: 1.51MB
Sale Price: 11.5$


Lenovo IdeaPad Y770 Block Diagram:
Lenovo IdeaPad Y770 Block Diagram

Lenovo IdeaPad Y770 Block Diagram
