Lenovo ThinkPad T420 schematic, NZM3I-6, H430UI1 UMA

The motherboard schematic for Lenovo ThinkPad T420 (UMA) laptop/notebook,
NZM3I-6
VER 6.06
Nov/25/2010
BASE LOGIC: NZM3 UMA SIT
VER 5.11
OCT/15/2010
CPU: Sandy Bridge + DDR3
Chipset: PCH COUGAR_POINT
OEM: Flex Computing
Project: H430UI1
Document Number: LNVH-40GAB5700-F100
Rev: F
Format: PDF
Total Pages: 99
File size: 1.47MB
Sale Price: 11.5$


ThinkPad T420 (UMA) schematics:
ThinkPad T420 (UMA) schematics

ThinkPad T420 (UMA) schematics
