Lenovo Thinkpad E565 Schematic CIMS1 LA-D214P

The motherboard schematic diagram for Lenovo Thinkpad S5 E560P laptop/notebook, Merlyn M/B Schematics Document, Intel Kaby Lake-H Processor + PCH with DDR4 + NVIDA N17P-G1 GPU, CIMS1 LA-D214P motherboard.
Model Name: CIMS1
File Name: LA-D214P
Document Number: Merlyn2 LA-D214P
Format: PDF (No watermark of website)
Total Sheet: 72
Language: English
Sale Price: 9.5$

Lenovo Thinkpad E565 Schematic CIMS1 LA-D214P
