Lenovo ThinkPad L570 Yoga 370 Schematic CILL1 CILL2 LA-C422P

The Schematic (*.pdf) for Lenovo ThinkPad L570, Lenovo Yoga 370 laptop, CILL1 CILL2 LA-C422P Motherboard.
Intel KabyLake U with DDR4 + Wild Cat Point PCH
GPU: UMA
EC: nuvoton NPCE388N
Format：PDF (Searchable)
Language: English
Pages: 58
Sale Price: 9.5$

Original document, no irrelevant watermark.
