Lenovo Thinkpad Edge E535 schematic, QALEA/QALEB LA-8124P

The motherboard schematic for Lenovo Thinkpad Edge E535 laptop/notebook, QALEA/QALEB Mainboard Compal LA-8124P, QALEA/QALEB Schematics Document.
CPU: AMD FS1r2 + Themes XT M2/Seymour XTX M2 (VRAM 64M16/128M16/256M16 DDR3 x 8)
Chipset: Hudson M3
OEM: Compal Electronics, Inc.
File Name : QALEA/QALEB
Document Number: LA-8124P
Rev: 0.4
Format: PDF
Total Pages: 50
File size: 1.49MB
Sale Price: 10.5$

Thinkpad Edge E535 Block Diagram:
