Lenovo Thinkpad P71 Schematic diagram, DP710 NM-B121 mainboard

Lenovo Schematics

The motherboard schematic diagram for Lenovo Thinkpad P71 laptop/notebook, DP710 NM-B121 mainboard.
CPU: Intel Kabylake-H
PCH: Intel Kabylake-H
GPU: MXM Card NVIDIA N17M-Q3 or N17EQ1/Q3/Q5 (DIS)
EC: MEC1653
Project Code: BP710
BOARD NO.: NM-B121
Document Number: PAYTON
OEM: LCFC
Format: PDF
Searchable PDF file, No watermark of website
Total Pages: 110
Sale Price: 12.5$

Lenovo Thinkpad P70 NM-A441 Block Diagram:
Lenovo Thinkpad P70 NM-A441 Block Diagram
