Toshiba Satellite L600D P205D (UMA) schematic,TE3

TOSHIBA Schematics

The motherboard schematic for Toshiba Satellite L600D, Toshiba Satellite P205D Series: P205D-S7436, P205D-S7438 laptop/notebook, Quanta TE3.
CPU: AMD S1g4
North Bridge: RX881/RS880MN/RS880MC
South Bridge: SB820
OEM: Quanta Computer Inc.
Project: TE3
Rev: 1A
Total Pages: 43
File size: 1.18MB
Sale Price: 10.5$


Toshiba Satellite L600D P205D Block Diagram:
Toshiba Satellite L600D P205D Block Diagram

Toshiba Satellite L600D P205D Block Diagram
