HP Pavilion DV6/DV7 Series schematic, DA0LX3MB8F0, 31LX3MB0090

The motherboard schematic for HP DV6 /DV7 Series laptop/notebook, Quanta LX3/LX5, DA0LX3MB8F0, 31LX3MB0090.
CPU: Intel Sandy 45Watt/35Watt 4 Core
Discrete VGA ATI Capliano Pro (128bit) / ATI Robson M2 (128bit)
Chipset: PCH 3.5Watt
OEM: Quanta Computer Inc.
Project: LX3/5(Huron River)
Rev: 1A
Format: PDF
Total Pages: 47
File size: 1.83MB
Sale Price: 11.5$

HP Pavilion DV6 DV7 Block Diagram:
