HP Pavilion 14/15/17 Series schematic, DA0R62MB6E1

The motherboard schematic for HP Pavilion 14/15/17 Series laptop/notebook, Quanta R62 Mainboard, DA0R62MB6E1.
CPU: INTEL IVY
Graphic AMD Mars / SUN XT
Chipset: INTEL PCH Panther Point
OEM: Quanta Computer Inc.
Project: R62
Rev: 1A
Format: PDF
Total Pages: 43
File size: 1.75MB
Sale Price: 11.5$

HP Pavilion 14/15/17 Block Diagram:
