HP Pavilion G6/G7 (UMA) schematic, Quanta R24

The motherboard schematic for HP Pavilion G6/G7 laptop/notebook. Quanta R24 UMA Mainboard, DA0R24MB6D0, DA0R24MB6F0.
CPU:AMD Ontario 18W
Chipset: AMD HUDSON-M1
OEM: Quanta Computer Inc
Project: R24
Rev: 1A
Format: PDF
Total Pages: 36
File size: 1.84MB
Sale Price: 10.5$


HP Pavilion G6 G7 (UMA) Block Diagram:
HP Pavilion G6 G7 (UMA) Block Diagram

HP Pavilion G6 G7 (UMA) Block Diagram
