Toshiba Satellite C805 schematic, BY3/BY4

The motherboard schematic for Toshiba Satellite C805 laptop/notebook, Quanta BY3/BY4 Mainboard.
CPU: Ivy Bridge(UMA+VGA) + VGA Thames_M2
Chipset: PantherPoint PCH
OEM:Quanta Computer Inc.
Document Number: WR1G2 MAIN BOARD
Rev: 1A1
Format: PDF
Total Pages: 48
File size: 1.11MB
Sale Price: 11.5$

Toshiba Satellite C805 Block Diagram:
