Toshiba Satellite L500/L500D/L550D/L555D schematic, UMA NSWAE LA-5332P

The motherboard schematic for Toshiba Satellite L500, Toshiba Satellite L500D, Toshiba Satellite L550D, Toshiba Satellite L555D laptop/notebook, NSWAE/NTWAE LA-5332P Schematics Document, Liverpool/Sunderland 10AT.
CPU: AMD S1G3
North Bridge: ATI RS880M/RS880MC
South Bridge: ATI SB710
OEM: Compal Electronics
Model Name: NSWAE & NTWAE UMA
File Name: LA-5332P
Document Number: 401721
Rev: C
Format: PDF
Total Pages: 45
File size: 723KB
Sale Price: 10.5$


Toshiba Satellite L500 Block Diagram:
Toshiba Satellite L500 Block Diagram

Toshiba Satellite L500 Block Diagram
